Machine · ConveyingRC-B1200 Overland Conveyor
1 200 mm overland belt in modules, transfer tower included.
Purpose
Haul from primary to the plant, or plant to stockpile
Capacity — 1 200 t/h at 18°; length by module
1 200 mm belt, 3.15 m/s, designed as a run of standard modules plus a transfer tower. Ridgecast supplies the idlers, pulleys, and the take-up; civil is the mine's.
Technical specifications
| Belt | 1 200 mm, ST 1250 |
|---|---|
| Speed | 3.15 m/s |
| Drive | 2 × 132 kW typical 400 m run |
Gallery
Not sure which machine the rock wants?
Send a rock sample and the target product. The applications desk sizes the machine from the sample, not from a brochure t/h.
